Not perforated
Return flanges
ETIM: EC000047
Return flanges
ETIM: EC000047
| HD | Reference |
mm |
mm |
mm |
mm |
kg m |
Stock | Unit | |
| - | KGI60.300.125S12 | 60 | 300 | 1.25 | 3000 | 4.811 | 30 | M | |
| - | KGI60.300.125S13 | 60 | 300 | 1.25 | 3000 | 4.811 | 30 | M | |
| - | KGI60.300.125S23 | 60 | 300 | 1.25 | 3000 | 5.322 | 30 | M | |
| - | KGI60.400.125S12 | 60 | 400 | 1.25 | 3000 | 5.811 | 30 | M | |
| - | KGI60.400.125S13 | 60 | 400 | 1.25 | 3000 | 5.811 | 30 | M | |
| - | KGI60.400.125S23 | 60 | 400 | 1.25 | 3000 | 6.322 | 30 | M | |
| - | KGI60.500.125S12 | 60 | 500 | 1.25 | 3000 | 6.811 | 30 | M | |
| - | KGI60.500.125S13 | 60 | 500 | 1.25 | 3000 | 6.811 | 30 | M | |
| - | KGI60.500.125S23 | 60 | 500 | 1.25 | 3000 | 7.322 | 30 | M | |
| - | KGI60.600.125S12 | 60 | 600 | 1.25 | 3000 | 7.811 | 30 | M | |
| - | KGI60.600.125S13 | 60 | 600 | 1.25 | 3000 | 7.811 | 30 | M | |
| - | KGI60.600.125S23 | 60 | 600 | 1.25 | 3000 | 8.322 | 30 | M |
HD
Reference
mm
mm
mm
mm
kg
m
Stock
Unit
- - KGI60.300.125S12 60 300 1.25 3000 4.811 30 M
- - KGI60.300.125S13 60 300 1.25 3000 4.811 30 M
- - KGI60.300.125S23 60 300 1.25 3000 5.322 30 M
- - KGI60.400.125S12 60 400 1.25 3000 5.811 30 M
- - KGI60.400.125S13 60 400 1.25 3000 5.811 30 M
- - KGI60.400.125S23 60 400 1.25 3000 6.322 30 M
- - KGI60.500.125S12 60 500 1.25 3000 6.811 30 M
- - KGI60.500.125S13 60 500 1.25 3000 6.811 30 M
- - KGI60.500.125S23 60 500 1.25 3000 7.322 30 M
- - KGI60.600.125S12 60 600 1.25 3000 7.811 30 M
- - KGI60.600.125S13 60 600 1.25 3000 7.811 30 M
- - KGI60.600.125S23 60 600 1.25 3000 8.322 30 M
