РусскийWire cable tray - VFUL60
Screen: 50 x 100 mm
Cross-wire: Ø 3.50 mm
Lengthwise wire: Ø 4.50 mm
ETIM: EC000853
Cross-wire: Ø 3.50 mm
Lengthwise wire: Ø 4.50 mm
ETIM: EC000853
| HD | Reference |
mm |
mm |
mm |
mm |
kg m |
Stock | Unit | |
| - | VFUL60.050 | 60 | 50 | 3000 | 0.570 | 30 | v | M | |
| - | VFUL60.100 | 60 | 96 | 3000 | 0.830 | 30 | v | M | |
| - | VFUL60.150 | 60 | 146 | 3000 | 0.870 | 30 | v | M | |
| - | VFUL60.200 | 60 | 197 | 3000 | 1.030 | 30 | v | M | |
| - | VFUL60.300 | 60 | 297 | 3000 | 1.330 | 30 | v | M | |
| - | ZAVFUL60.050 | 60 | 50 | 3000 | 0.570 | 30 | M | ||
| - | ZAVFUL60.100 | 60 | 100 | 3000 | 0.830 | 30 | M | ||
| - | ZAVFUL60.150 | 60 | 146 | 3000 | 0.870 | 30 | M | ||
| - | ZAVFUL60.200 | 60 | 197 | 3000 | 1.030 | 30 | M | ||
| - | ZAVFUL60.300 | 60 | 297 | 3000 | 1.330 | 30 | M |
HD
Reference
mm
mm
mm
mm
kg
m
Stock
Unit
- - VFUL60.050 60 50 3000 0.570 30 v M
- - VFUL60.100 60 96 3000 0.830 30 v M
- - VFUL60.150 60 146 3000 0.870 30 v M
- - VFUL60.200 60 197 3000 1.030 30 v M
- - VFUL60.300 60 297 3000 1.330 30 v M
- - ZAVFUL60.050 60 50 3000 0.570 30 M
- - ZAVFUL60.100 60 100 3000 0.830 30 M
- - ZAVFUL60.150 60 146 3000 0.870 30 M
- - ZAVFUL60.200 60 197 3000 1.030 30 M
- - ZAVFUL60.300 60 297 3000 1.330 30 M
