РусскийCable tray with interlocking ends - KBSI60
Interlocking ends
Alternative perforations
Return flanges
ETIM: EC000047
Alternative perforations
Return flanges
ETIM: EC000047
| HD | Reference |
mm |
mm |
mm |
mm |
kg m |
Stock | Unit | |
| - | KBSI60.075.125 | 60 | 75 | 1.25 | 3000 | 1.815 | 60 | v | M |
| - | KBSI60.100.125 | 60 | 100 | 1.25 | 3000 | 2.089 | 60 | v | M |
| - | KBSI60.150.125 | 60 | 150 | 1.25 | 3000 | 2.525 | 30 | v | M |
| - | KBSI60.200.125 | 60 | 200 | 1.25 | 3000 | 2.974 | 30 | v | M |
| - | KBSI60.300.125 | 60 | 300 | 1.25 | 3000 | 3.867 | 30 | v | M |
| - | KBSI60.400.125 | 60 | 400 | 1.25 | 3000 | 4.804 | 30 | v | M |
| - | KBSI60.500.125 | 60 | 500 | 1.25 | 3000 | 5.726 | 30 | v | M |
| - | KBSI60.600.125 | 60 | 600 | 1.25 | 3000 | 6.655 | 30 | v | M |
HD
Reference
mm
mm
mm
mm
kg
m
Stock
Unit
- - KBSI60.075.125 60 75 1.25 3000 1.815 60 v M
- - KBSI60.100.125 60 100 1.25 3000 2.089 60 v M
- - KBSI60.150.125 60 150 1.25 3000 2.525 30 v M
- - KBSI60.200.125 60 200 1.25 3000 2.974 30 v M
- - KBSI60.300.125 60 300 1.25 3000 3.867 30 v M
- - KBSI60.400.125 60 400 1.25 3000 4.804 30 v M
- - KBSI60.500.125 60 500 1.25 3000 5.726 30 v M
- - KBSI60.600.125 60 600 1.25 3000 6.655 30 v M
