РусскийPerforated cable tray - KBS60
Alternative perforation
Return flanges
ETIM: EC000047
Return flanges
ETIM: EC000047
| HD | Reference |
mm |
mm |
mm |
mm |
kg m |
Stock | Unit | |
| - | ZMKBS60.050.075 | 60 | 50 | 0.75 | 3000 | 0.948 | 60 | M | |
| - | ZMKBS60.050.100 | 60 | 50 | 0.90 | 3000 | 1.216 | 60 | M | |
| - | ZMKBS60.100.150 | 60 | 100 | 1.50 | 3000 | 2.549 | 60 | M | |
| - | ZMKBS60.150.150 | 60 | 150 | 1.50 | 3000 | 3.124 | 30 | M | |
| - | ZMKBS60.200.150 | 60 | 200 | 1.50 | 3000 | 3.687 | 30 | M | |
| - | ZMKBS60.300.150 | 60 | 300 | 1.50 | 3000 | 4.780 | 30 | M | |
| - | ZMKBS60.400.150 | 60 | 400 | 1.50 | 3000 | 5.957 | 30 | M | |
| - | ZMKBS60.500.150 | 60 | 500 | 1.50 | 3000 | 7.091 | 30 | M | |
| - | ZMKBS60.600.150 | 60 | 600 | 1.50 | 3000 | 8.243 | 30 | M | |
| HD | KBS60.050.075 | 60 | 50 | 0.75 | 3000 | 0.948 | 3 | v | M |
| HD | KBS60.050.100 | 60 | 50 | 1 | 3000 | 1.216 | 3 | v | M |
| HD | KBS60.100.150 | 60 | 100 | 1.5 | 3000 | 2.549 | 60 | v | M |
| HD | KBS60.150.150 | 60 | 150 | 1.5 | 3000 | 3.124 | 30 | v | M |
| HD | KBS60.200.150 | 60 | 200 | 1.5 | 3000 | 3.687 | 30 | v | M |
| HD | KBS60.300.150 | 60 | 300 | 1.5 | 3000 | 4.780 | 30 | v | M |
| HD | KBS60.400.150 | 60 | 400 | 1.5 | 3000 | 5.957 | 30 | v | M |
| HD | KBS60.500.150 | 60 | 500 | 1.5 | 3000 | 7.091 | 30 | v | M |
| HD | KBS60.600.150 | 60 | 600 | 1.5 | 3000 | 8.243 | 30 | v | M |
HD
Reference
mm
mm
mm
mm
kg
m
Stock
Unit
- - ZMKBS60.050.075 60 50 0.75 3000 0.948 60 M
- - ZMKBS60.050.100 60 50 0.90 3000 1.216 60 M
- - ZMKBS60.100.150 60 100 1.50 3000 2.549 60 M
- - ZMKBS60.150.150 60 150 1.50 3000 3.124 30 M
- - ZMKBS60.200.150 60 200 1.50 3000 3.687 30 M
- - ZMKBS60.300.150 60 300 1.50 3000 4.780 30 M
- - ZMKBS60.400.150 60 400 1.50 3000 5.957 30 M
- - ZMKBS60.500.150 60 500 1.50 3000 7.091 30 M
- - ZMKBS60.600.150 60 600 1.50 3000 8.243 30 M
- HD KBS60.050.075 60 50 0.75 3000 0.948 3 v M
- HD KBS60.050.100 60 50 1 3000 1.216 3 v M
- HD KBS60.100.150 60 100 1.5 3000 2.549 60 v M
- HD KBS60.150.150 60 150 1.5 3000 3.124 30 v M
- HD KBS60.200.150 60 200 1.5 3000 3.687 30 v M
- HD KBS60.300.150 60 300 1.5 3000 4.780 30 v M
- HD KBS60.400.150 60 400 1.5 3000 5.957 30 v M
- HD KBS60.500.150 60 500 1.5 3000 7.091 30 v M
- HD KBS60.600.150 60 600 1.5 3000 8.243 30 v M
